10.ns3 路由性能测试实例

Config::ConnectWithoutContext("/NodeList/*/ApplicationList/*/$ns3::PacketSink/Rx", MakeCallback(&OrrpExample::ReceivePacket, this));

void OrrpExample::ReceivePacket(Ptr<const Packet> packet, const Address &)

{

    if ((Simulator::Now() - tmp) < Seconds(1))

    {

        tmpTotal += packet->GetSize();

    }

    else

    {

        while ((Simulator::Now() - tmp) > Seconds(1))

        {

            std::cout << tmp.GetSeconds() << "S throughoutput = " << tmpTotal * 8 / (1e6) << "Mbit" << std::endl;

            std::ostringstream ostrStream;

            ostrStream << "./result/" << m_protocolName << "Test/" << m_protocolName << "Test-size-" << size << "-seed-" << seed << "-nodesLocationType-" << nodesLocationType << "-nodesMove-" << nodesMove << "-width-" << width << "-step-" << step << "-log";

            std::ofstream file(ostrStream.str(), std::ios::app | std::ios::out);

            file << tmp.GetSeconds() << " " << sendSeq.size() * packet->GetSize() * 8 / (1e6) << " " << bytesTotal * 8 / (1e6) << " " << tmpTotal * 8 / (1e6) << "\n";

            file.close();

            tmp += Seconds(1);

            tmpTotal = 0;

        }

        tmpTotal += packet->GetSize();

    }

    std::vector<uint32_t>::iterator iter;

    iter = find(sendSeq.begin(), sendSeq.end(), packet->GetUid());

    int index = iter - sendSeq.begin();

    bytesTotal += packet->GetSize();

    packetsReceived += 1;

    m_delayEstimation.RecordRx(packet);

    m_delay += (Simulator::Now() - sendTime[index]).GetSeconds();

    m_jitter += m_delayEstimation.GetLastJitter();

    if (first_pkt)

    {

        m_firstRx = Simulator::Now();

        first_pkt = false;

    }

    m_lastRx = Simulator::Now();

}

int main(int argc, char **argv)

{

    OrrpExample test;

    if (!test.Configure(argc, argv))

    {

        NS_FATAL_ERROR("Configuration failed. Aborted.");

    }

    test.Run();

    test.ReportStatistics();

    test.Report(std::cout);

    return 0;

}

void OrrpExample::ReportStatistics()

{

    double Dt = m_lastRx.GetSeconds() - m_firstRx.GetSeconds();

    double kbs = (bytesTotal * 8.0) / (Dt * 1000);

    bytesTotal = 0;

    std::ofstream out(m_CSVfileName.c_str(), std::ios::app);

    int m_nSinks = 1;

    out << kbs / m_nSinks << ","

        << packetsReceived << ","

        << packetsTx << ","

        << packetsReceived / (double)packetsTx << ","

        << m_delay / packetsReceived << ","

        << m_jitter / (packetsReceived * 1000000000.0) << ","

        //   << routingPkts << ","

        //    << m_nSinks << ","

        //    << m_nWifis << ","

        //    << m_protocolName << ","

        //   << m_txrange << ""

        << std::endl;

    std::cout << "吞吐量 " << kbs / m_nSinks << " kbps ,"

              << "收包数" << packetsReceived << ","

              << "发包数" << packetsTx << ","

              << "交付率" << packetsReceived / (double)packetsTx << ","

              << "时延" << m_delay / packetsReceived << ","

              << m_jitter / (packetsReceived * 1000000000.0) << ","

              << std::endl;

    std::ostringstream ostrStream;

    ostrStream << "./result/" << m_protocolName << "Test/" << m_protocolName << "Test-size-" << size << "-seed-" << seed << "-nodesLocationType-" << nodesLocationType << "-nodesMove-" << nodesMove << "-width-" << width << "-step-" << step << "-delay-log";

    std::ofstream file(ostrStream.str(), std::ios::app | std::ios::out);

    file << packetsReceived / (double)packetsTx << " " << m_delay / packetsReceived << " " << kbs / m_nSinks / 1e3 << "\n";

    file.close();

    out.close();

    packetsReceived = 0;

    packetsTx = 0;

    m_delay = 0;

    m_jitter = 0;

    // routingPkts = 0;

}

void OrrpExample::CalculateThroughput(double endTime)

{

    std::ostringstream ostrStream;

    ostrStream << "./result/orrpTest/orrpTest-size-" << size << "-seed-" << seed << "-nodesLocationType-" << nodesLocationType << "-nodesMove-" << nodesMove << "-width-" << width << "-step-" << step << "-log";

    std::ofstream file;

    file.open(ostrStream.str(), std::ios_base::app);

    Time now = Simulator::Now();

    double cur = (sink->GetTotalRx() - lastTotalRx) * (double)8 / 1e6;

    double TotalRx = sink->GetTotalRx() * (double)8 / 1e6;

    double TotalTx = source->GetTotalTx() * (double)8 / 1e6;

    file << now.GetSeconds() << " " << TotalTx << " " << TotalRx << " " << cur << "\n";

    //  std::cout<<now.GetSeconds () << "s 发送数据: \t" <<"send:"<<source->GetTotalTx ()* (double) 8 / 1e6<<"Mbit"<<std::endl;

    //  std::cout<<now.GetSeconds () << "s 接收数据: \t" <<"receive:"<<sink->GetTotalRx ()* (double) 8 / 1e6<<"Mbit"<<std::endl;

    std::cout << now.GetSeconds() << "s吞吐量: \t" << cur << " Mbit/s" << std::endl; // throughput

                                                                                     // std::cout << now.GetSeconds () << cur << std::endl;//throughput

    lastTotalRx = sink->GetTotalRx();

    file.close();

    if (now < Seconds(endTime))

        //  Simulator::Schedule (MilliSeconds (100), &OrrpExample::CalculateThroughput,this,endTime);

        Simulator::Schedule(Seconds(1), &OrrpExample::CalculateThroughput, this, endTime);

}

#include <vector>

#include <iostream>

#include <cmath>

#include "ns3/aodv-module.h"

#include "ns3/orrp-module.h"

#include "ns3/orrp2d-helper.h"

#include "ns3/core-module.h"

#include "ns3/network-module.h"

#include "ns3/internet-module.h"

#include "ns3/mobility-module.h"

#include "ns3/point-to-point-module.h"

#include "ns3/v4ping-helper.h"

#include "ns3/optical-helper.h"

#include "ns3/applications-module.h"

// add by yeyu

#include "ns3/MyPropagationLossModel.h"

#include "ns3/stats-module.h"

#include "ns3/netanim-module.h"

#include <sstream>

#include <string>

using namespace ns3;

//********************* stats result******************//

// 输出结果

//  void ReportStatistics ();

// send callback

void TxPacket(Ptr<const Packet>);

// 打印进度

void PrintProgress(double TotalTime);

// 接收回调

// void ReceivePacket (Ptr<const Packet> packet, const Address &);

uint32_t bytesTotal(0);

uint32_t bytesReceivedTotal(0);

uint32_t packetsReceived(0);

uint32_t packetsTx(0);

DelayJitterEstimation m_delayEstimation;

double m_delay(0);

uint64_t m_jitter(0);

bool first_pkt(true);

std::string m_CSVfileName("orrpTest-routing-output");

Time m_firstRx;

Time m_lastRx;

Time tmp;

uint32_t tmpTotal(0);

std::vector<Time> sendTime;

std::vector<uint32_t> sendSeq;

//********************* stats result******************//

// 接收端应用

Ptr<PacketSink> sink; /* Pointer to the packet sink application */

// 发送端应用

Ptr<OnOffApplication> source;

uint64_t lastTotalRx = 0; /* The value of the last total received bytes */

class OrrpExample

{

public:

    OrrpExample();

    bool Configure(int argc, char **argv);

    void Run();

    /**

     * Report results

     * \param os the output stream

     */

    void Report(std::ostream &os);

    void printRoute(double showTime);

    void CalculateThroughput(double endTime);

    void PhyRxOkTrace(std::string context, Ptr<const Packet> packet, double snr, WifiMode mode, enum WifiPreamble preamble);

    void DevTxTrace(std::string context, Ptr<const Packet> packet);

    void DevRxTrace(std::string context, Ptr<const Packet> packet);

    void ReceivePacket(Ptr<const Packet> packet, const Address &);

    void ReportStatistics();

    void energyChanged(double oldValue, double newValue);

private:

    // parameters

    /// 节点数量

    uint32_t size;

    /// 采用网格布局时节点的距离

    double step;

    /// 仿真总时间 (s)

    double totalTime;

    /// Write per-device PCAP traces if true

    bool pcap;

    /// 是否打印路由表

    bool printRoutes;

    bool nodesMove;

    double m_energyCost;

    double m_energyInit;

    // 节点布局方式 (0: 网格布局；1: 矩形随机布局)

    int nodesLocationType;

    // 随机

    int seed;

    int width;

    // yeyu

    WifiHelper wifi;

    std::vector<Ptr<WifiPhy>> m_phyVector;

    std::string m_protocolName;

    int m_routingProtocol;

    NodeContainer nodes;

    NetDeviceContainer devices;

    Ipv4InterfaceContainer interfaces;

private:

    void CreateNodes();

    void CreateDevices();

    void InstallInternetStack();

    void InstallApplications();

};

void OrrpExample::ReceivePacket(Ptr<const Packet> packet, const Address &)

{

    if ((Simulator::Now() - tmp) < Seconds(1))

    {

        tmpTotal += packet->GetSize();

    }

    else

    {

        while ((Simulator::Now() - tmp) > Seconds(1))

        {

            std::cout << tmp.GetSeconds() << "S throughoutput = " << tmpTotal * 8 / (1e6) << "Mbit" << std::endl;

            std::ostringstream ostrStream;

            ostrStream << "./result/" << m_protocolName << "Test/" << m_protocolName << "Test-size-" << size << "-seed-" << seed << "-nodesLocationType-" << nodesLocationType << "-nodesMove-" << nodesMove << "-width-" << width << "-step-" << step << "-log";

            std::ofstream file(ostrStream.str(), std::ios::app | std::ios::out);

            file << tmp.GetSeconds() << " " << sendSeq.size() * packet->GetSize() * 8 / (1e6) << " " << bytesTotal * 8 / (1e6) << " " << tmpTotal * 8 / (1e6) << "\n";

            file.close();

            tmp += Seconds(1);

            tmpTotal = 0;

        }

        tmpTotal += packet->GetSize();

    }

    std::vector<uint32_t>::iterator iter;

    iter = find(sendSeq.begin(), sendSeq.end(), packet->GetUid());

    int index = iter - sendSeq.begin();

    bytesTotal += packet->GetSize();

    packetsReceived += 1;

    m_delayEstimation.RecordRx(packet);

    //          m_delay += m_delayEstimation.GetLastDelay().GetNanoSeconds();

    m_delay += (Simulator::Now() - sendTime[index]).GetSeconds();

    m_jitter += m_delayEstimation.GetLastJitter();

    //          std::cout<<tmp.GetSeconds()<<"s "<<tmpTotal<<"Byte "<<Simulator::Now().GetSeconds()<<"uid:"<<packet->GetUid()<<" received packet delay="<<(Simulator::Now()-sendTime[index]).GetSeconds()<<"s size= "<<packet->GetSize ()<<std::endl;

    if (first_pkt)

    {

        m_firstRx = Simulator::Now();

        first_pkt = false;

    }

    m_lastRx = Simulator::Now();

}

void TxPacket(Ptr<const Packet> pkt)

{

    // trace packet

    packetsTx += 1;

    m_delayEstimation.PrepareTx(pkt);

    sendSeq.push_back(pkt->GetUid());

    sendTime.push_back(Simulator::Now());

    //    std::cout<<Simulator::Now().GetSeconds()<<"uid:"<<pkt->GetUid()<<" send"<<std::endl;

}

void PrintProgress(double TotalTime)

{

    double now = Simulator::Now().GetSeconds();

    NS_LOG_UNCOND("Progress Completed .. " << (now / TotalTime) * 100 << "%");

    Simulator::Schedule(Seconds(TotalTime / 100), &PrintProgress, TotalTime);

}

void OrrpExample::ReportStatistics()

{

    double Dt = m_lastRx.GetSeconds() - m_firstRx.GetSeconds();

    double kbs = (bytesTotal * 8.0) / (Dt * 1000);

    bytesTotal = 0;

    std::ofstream out(m_CSVfileName.c_str(), std::ios::app);

    int m_nSinks = 1;

    out << kbs / m_nSinks << ","

        << packetsReceived << ","

        << packetsTx << ","

        << packetsReceived / (double)packetsTx << ","

        << m_delay / packetsReceived << ","

        << m_jitter / (packetsReceived * 1000000000.0) << ","

        //   << routingPkts << ","

        //    << m_nSinks << ","

        //    << m_nWifis << ","

        //    << m_protocolName << ","

        //   << m_txrange << ""

        << std::endl;

    std::cout << "吞吐量 " << kbs / m_nSinks << " kbps ,"

              << "收包数" << packetsReceived << ","

              << "发包数" << packetsTx << ","

              << "交付率" << packetsReceived / (double)packetsTx << ","

              << "时延" << m_delay / packetsReceived << ","

              << m_jitter / (packetsReceived * 1000000000.0) << ","

              << std::endl;

    std::ostringstream ostrStream;

    ostrStream << "./result/" << m_protocolName << "Test/" << m_protocolName << "Test-size-" << size << "-seed-" << seed << "-nodesLocationType-" << nodesLocationType << "-nodesMove-" << nodesMove << "-width-" << width << "-step-" << step << "-delay-log";

    std::ofstream file(ostrStream.str(), std::ios::app | std::ios::out);

    file << packetsReceived / (double)packetsTx << " " << m_delay / packetsReceived << " " << kbs / m_nSinks / 1e3 << "\n";

    file.close();

    out.close();

    packetsReceived = 0;

    packetsTx = 0;

    m_delay = 0;

    m_jitter = 0;

    // routingPkts = 0;

}

int main(int argc, char **argv)

{

    OrrpExample test;

    if (!test.Configure(argc, argv))

    {

        NS_FATAL_ERROR("Configuration failed. Aborted.");

    }

    test.Run();

    test.ReportStatistics();

    test.Report(std::cout);

    return 0;

}

//-----------------------------------------------------------------------------

OrrpExample::OrrpExample() : size(30),

                             step(40),

                             totalTime(20),

                             pcap(false),

                             printRoutes(true),

                             seed(1),

                             width(size / 5),

                             nodesMove(false),

                             nodesLocationType(0),

                             m_energyInit(1),

                             m_energyCost(0),

                             m_routingProtocol(2),

                             m_protocolName("aodv")

{

}

bool OrrpExample::Configure(int argc, char **argv)

{

    // Enable ORRP logs by default. Comment this if too noisy

    //

    //   LogComponentEnable("OrrpNeighbors", LOG_LEVEL_WARN);

    //   LogComponentEnable("OrrpNeighbors", LOG_LEVEL_WARN);

    //   LogComponentEnable("OrrpRoutingTable", LOG_LEVEL_WARN);

    LogComponentEnable("Orrp2dRoutingProtocol", LOG_LEVEL_ERROR);

    LogComponentEnable("Orrp2dNeighbors", LOG_LEVEL_ERROR);

    //   LogComponentEnable("OrrpRoutingProtocol", LOG_LEVEL_ALL);

    //  LogComponentEnable("BasicEnergySource", LOG_LEVEL_ALL);

    //  LogComponentEnable("MyLossModel",LOG_LEVEL_ALL);

    //  LogComponentEnable("YansWifiChannel",LOG_LEVEL_ALL);

    //  LogComponentEnable("MyPacketSink",LOG_LEVEL_ALL);

    //  LogComponentEnable("OrrpRoutingProtocol",LOG_LEVEL_ALL);

    CommandLine cmd(__FILE__);

    cmd.AddValue("pcap", "Write PCAP traces.", pcap);

    cmd.AddValue("printRoutes", "Print routing table dumps.", printRoutes);

    cmd.AddValue("size", "Number of nodes.", size);

    cmd.AddValue("time", "Simulation time, s.", totalTime);

    cmd.AddValue("route", "routing protocol name", m_routingProtocol);

    cmd.AddValue("step", "Grid step, m", step);

    cmd.AddValue("seed", "seed", seed);

    cmd.AddValue("width", "grid width", width);

    cmd.AddValue("nodesMove", "nodes move?", nodesMove);

    cmd.AddValue("nodesLocationType", "the type of nodes location", nodesLocationType);

    cmd.Parse(argc, argv);

    SeedManager::SetSeed(seed);

    return true;

}

void OrrpExample::PhyRxOkTrace(std::string context, Ptr<const Packet> packet, double snr, WifiMode mode, enum WifiPreamble preamble)

{

    std::cout << "PHYRXOK mode=" << mode << " snr=" << snr << " PacketSize= " << packet->GetSize() << std::endl;

}

void OrrpExample::DevTxTrace(std::string context, Ptr<const Packet> p)

{

    std::cout << " TX p size = " << p->GetSize() << std::endl;

}

void OrrpExample::DevRxTrace(std::string context, Ptr<const Packet> p)

{

    std::cout << " RX p size = : " << p->GetSize() << std::endl;

}

void OrrpExample::Run()

{

    Config::SetDefault("ns3::WifiRemoteStationManager::RtsCtsThreshold", UintegerValue(10)); // enable rts cts all the time.

    CreateNodes();

    CreateDevices();

    //  Config::Connect ("/NodeList/*/DeviceList/*/Phy/State/RxOk", MakeCallback (&OrrpExample::PhyRxOkTrace,this));

    //  Config::Connect ("/NodeList/*/DeviceList/*/Mac/MacRx", MakeCallback (&OrrpExample::DevRxTrace,this));

    //  Config::Connect ("/NodeList/*/DeviceList/*/Mac/MacTx", MakeCallback (&OrrpExample::DevTxTrace,this));

    InstallInternetStack();

    InstallApplications();

    std::cout << "Starting simulation for " << totalTime << " s ...\n";

    // 动画显示

    AnimationInterface anim("2dTest.xml");

    anim.SetMaxPktsPerTraceFile(99999999999999);

    anim.EnableIpv4RouteTracking("2dTest.route", Seconds(0), Seconds(totalTime), Seconds(1));

    Simulator::Stop(Seconds(totalTime));

    Simulator::Run();

    //  Config::Connect ("/NodeList/*/DeviceList/*/Phy/State/RxOk", MakeCallback (&OrrpExample::PhyRxOkTrace2,this));

    //  Config::Connect ("/NodeList/*/DeviceList/*/Phy/State/RxOk", MakeCallback (&PhyRxOkTrace));

    Simulator::Destroy();

}

void OrrpExample::Report(std::ostream &)

{

}

void OrrpExample::CreateNodes()

{

    std::cout << "Creating " << (unsigned)size << " nodes " << step << " m apart.\n";

    nodes.Create(size);

    // Name nodes

    for (uint32_t i = 0; i < size; ++i)

    {

        std::ostringstream os;

        os << "node-" << i;

        Names::Add(os.str(), nodes.Get(i));

    }

    // Create static grid

    MobilityHelper mobility;

    // 节点是否移动

    if (nodesMove)

    {

        mobility.SetMobilityModel("ns3::RandomWalk2dMobilityModel",

                                  "Mode", StringValue("Time"),

                                  "Direction", StringValue("ns3::UniformRandomVariable[Min=0.0|Max=6.283184]"),

                                  //                          "Time", StringValue("0.5s"),

                                  "Speed", StringValue("ns3::UniformRandomVariable[Min=0.0|Max=4.0]"),

                                  //                           "Speed", StringValue("ns3::ConstantRandomVariable[Constant=5.0]"),

                                  "Bounds", StringValue("0|1000|0|1000"));

    }

    // 节点初始部署位置

    switch (nodesLocationType)

    {

    case 0:

        mobility.SetPositionAllocator("ns3::GridPositionAllocator",

                                      "MinX", DoubleValue(100.0),

                                      "MinY", DoubleValue(100.0),

                                      "DeltaX", DoubleValue(step),

                                      "DeltaY", DoubleValue(step),

                                      "GridWidth", UintegerValue(width),

                                      "LayoutType", StringValue("RowFirst"));

        std::cout << "采用网格布局 width = " << width << std::endl;

        break;

    case 1:

        double tmp = 200;

        // 设置节点部署在 200*200 米随机位置

        mobility.SetPositionAllocator("ns3::RandomBoxPositionAllocator",

                                      "X", StringValue("ns3::UniformRandomVariable[Min=0.0|Max=200.0]"),

                                      "Y", StringValue("ns3::UniformRandomVariable[Min=0.0|Max=200.0]"),

                                      "Z", StringValue("ns3::UniformRandomVariable[Min=0.0|Max=0.0]"));

        std::cout << "采用200*200随机2维部署" << std::endl;

        break;

    }

    mobility.Install(nodes);

}

void singleDirectionSend(WifiHelper wifi, double transmitDirectAngel, double theta)

{

    std::vector<Ptr<WifiPhy>> m_phyVector = wifi.getPhyVector();

    for (uint32_t i = 0; i < m_phyVector.size(); i++)

    {

        m_phyVector[i]->setTransmitMode(1);

        m_phyVector[i]->setTransmitDirectAngel(transmitDirectAngel);

        m_phyVector[i]->setTheta(theta);

    }

}

void fourDirectionSend(WifiHelper wifi, double pianzhuanAngel, double angel)

{

    std::vector<Ptr<WifiPhy>> m_phyVector = wifi.getPhyVector();

    for (uint32_t i = 0; i < m_phyVector.size(); i++)

    {

        m_phyVector[i]->setTransmitDirectAngel(pianzhuanAngel);

        m_phyVector[i]->setTheta(angel);

    }

}

void twoDirectionSend(WifiHelper wifi, double transmitDirectAngel, double angel)

{

    std::vector<Ptr<WifiPhy>> m_phyVector = wifi.getPhyVector();

    for (uint32_t i = 0; i < m_phyVector.size(); i++)

    {

        m_phyVector[i]->setTransmitMode(2);

        m_phyVector[i]->setTransmitDirectAngel(transmitDirectAngel);

        m_phyVector[i]->setTheta(angel);

    }

}

void OrrpExample::CreateDevices()

{

    WifiMacHelper wifiMac;

    wifiMac.SetType("ns3::AdhocWifiMac");

    OpticalPhyHelper opticalPhy = OpticalPhyHelper::Default();

    OpticalChannelHelper opticalChannel = OpticalChannelHelper::Default();

    // add loss

    //   Ptr<MyPropagationLossModel> lossModel=CreateObject<MyPropagationLossModel>();

    //   lossModel->SetCLamada(0.151);

    //  Ptr<YansWifiChannel> myChannel=wifiChannel.Create();

    //   myChannel->SetPropagationLossModel(lossModel);

    opticalPhy.SetChannel(opticalChannel.Create());

    opticalPhy.Set("TxPowerStart", DoubleValue(16.0206));

    opticalPhy.Set("TxPowerEnd", DoubleValue(16.0206));

    opticalPhy.Set("TxPowerLevels", UintegerValue(1));

    //  opticalPhy.Set("TxGain", DoubleValue(1));

    //  opticalPhy.Set("RxGain", DoubleValue(1));

    //  opticalPhy.Set("RxSensitivity", DoubleValue(-96));

    //  opticalPhy.Set("CcaEdThreshold", DoubleValue(-99));

    // wifi.SetRemoteStationManager ("ns3::ConstantRateWifiManager", "DataMode", StringValue ("OfdmRate6Mbps"), "RtsCtsThreshold", UintegerValue (0));

    //  wifi.SetRemoteStationManager ("ns3::MinstrelHtWifiManager");

    devices = wifi.Install(opticalPhy, wifiMac, nodes);

    // create trace file

    //   AsciiTraceHelper ascii;

    //   wifiPhy.EnableAscii(ascii.CreateFileStream ("orrp.tr"),nodes);

}

void OrrpExample::printRoute(double showTime)

{

    Ptr<OutputStreamWrapper> routingStream = Create<OutputStreamWrapper>("ArouteTest.routes", std::ios::out);

    orrp.PrintRoutingTableAllAt(Seconds(showTime), routingStream);

}

void OrrpExample::InstallInternetStack()

{

    // you can configure ORRP attributes here using orrp.Set(name, value)

    InternetStackHelper stack;

    switch (m_routingProtocol)

    {

    case 2:

    {

        Orrp2dHelper orrp;

        std::ostringstream os;

        os << "10.0.0." << size;

        orrp.m_dst = Ipv4Address(os.str().c_str());

        orrp.m_origin = Ipv4Address("10.0.0.1");

        stack.SetRoutingHelper(orrp); // has effect on the next Install ()

        m_protocolName = "orrp2d";

        std::cout << "used orrp2d routing proto" << std::endl;

        if (printRoutes)

        {

            Ptr<OutputStreamWrapper> routingStream = Create<OutputStreamWrapper>("2dTest.routes", std::ios::out);

            orrp.PrintRoutingTableAllAt(Seconds(totalTime - 0.2), routingStream);

        }

    }

    break;

    case 1:

    {

        OrrpHelper orrp;

        stack.SetRoutingHelper(orrp); // has effect on the next Install ()

        m_protocolName = "orrp";

        std::cout << "used orrp routing proto" << std::endl;

        if (printRoutes)

        {

            Ptr<OutputStreamWrapper> routingStream = Create<OutputStreamWrapper>("orrpTest.routes", std::ios::out);

            orrp.PrintRoutingTableAllAt(Seconds(totalTime - 0.2), routingStream);

        }

    }

    break;

    case 0:

    {

        AodvHelper aodv;

        stack.SetRoutingHelper(aodv); // has effect on the next Install ()

        m_protocolName = "aodv";

        std::cout << "used aodv routing proto" << std::endl;

        if (printRoutes)

        {

            Ptr<OutputStreamWrapper> routingStream = Create<OutputStreamWrapper>("aodvTest.routes", std::ios::out);

            aodv.PrintRoutingTableAllAt(Seconds(totalTime - 0.2), routingStream);

        }

    }

    break;

    }

    //  OrrpHelper orrp;

    //  stack.SetRoutingHelper (orrp); // has effect on the next Install ()

    stack.Install(nodes);

    Ipv4AddressHelper address;

    address.SetBase("10.0.0.0", "255.0.0.0");

    interfaces = address.Assign(devices);

}

void OrrpExample::CalculateThroughput(double endTime)

{

    /*

   std::ostringstream ostrStream;

   ostrStream << "./result/orrpTest/orrpTest-size-"<<size<<"-seed-"<<seed<<"-nodesLocationType-"<<nodesLocationType<<"-nodesMove-"<<nodesMove<<"-width-"<<width<<"-step-"<<step<<"-log";

    std::ofstream file;

    file.open (ostrStream.str (),std::ios_base::app);

    Time now = Simulator::Now ();

    double cur = (sink->GetTotalRx () - lastTotalRx) * (double) 8 / 1e6;

    double TotalRx=sink->GetTotalRx ()* (double) 8 / 1e6;

    double TotalTx=source->GetTotalTx ()* (double) 8 / 1e6;

    file<<now.GetSeconds ()<<""<<TotalTx<<" "<<TotalRx<<" "<<cur<<"\n";

  //  std::cout<<now.GetSeconds () << "s 发送数据: \t" <<"send:"<<source->GetTotalTx ()* (double) 8 / 1e6<<"Mbit"<<std::endl;

  //  std::cout<<now.GetSeconds () << "s 接收数据: \t" <<"receive:"<<sink->GetTotalRx ()* (double) 8 / 1e6<<"Mbit"<<std::endl;

    std::cout << now.GetSeconds () << "s 吞吐量: \t" << cur << "Mbit/s" << std::endl;//throughput

     //std::cout << now.GetSeconds () << cur << std::endl;//throughput

    lastTotalRx = sink->GetTotalRx ();

    file.close ();

    if (now<Seconds (endTime))

      //  Simulator::Schedule (MilliSeconds (100), &OrrpExample::CalculateThroughput,this,endTime);

        Simulator::Schedule (Seconds (1), &OrrpExample::CalculateThroughput,this,endTime);

        */

}

void writeData()

{

    /*

      std::vector<Time> sendTime=source->getSendTimeList ();

      std::vector<Time> receiveTime=sink->getReceiveTimeList ();

      std::vector<uint32_t> sendSeq=source->getSendSeqList ();

      std::vector<uint32_t> receiveSeq=sink->getReceiveSeqList ();

      Time now = Simulator::Now ();

      double TotalRx=sink->GetTotalRx ()* (double) 8 / 1e6;

      double TotalTx=source->GetTotalTx ()* (double) 8 / 1e6;

      double avgThroughput=TotalRx/(sendTime [sendTime.size ()-1]-sendTime [0]).GetSeconds ();

      std::vector<Time> delayList;

      delayList.insert (delayList.begin (),sendTime.size (),Time ());

      Time totalDelay=Time ();

      for (uint32_t i=0;i<receiveTime.size ();i++){

          int seq=receiveSeq [i];

          delayList [seq]=receiveTime [i]-sendTime [seq];

          std::cout<<"序列号:"<<seq<<"的包时延是"<<delayList [seq].GetSeconds ()<<"S"<<std::endl;

          totalDelay+=delayList [seq];

      }

      //output to file

      std::ofstream file;

      file.open ("./result/orrpTest/orrpTest-delay-log",std::ios_base::app);

      file<<(double) receiveTime.size ()/sendTime.size ()<<""<<(totalDelay/receiveTime.size ()).GetSeconds ()<<" "<<avgThroughput<<"\n";

      std::cout<<"丢包率:"<<1-(double) receiveTime.size ()/sendTime.size ()<<std::endl;

      std::cout<<"平均时延:"<<(totalDelay/receiveTime.size ()).GetSeconds ()<<std::endl;

      std::cout<<"平均吞吐量:"<<avgThroughput<<std::endl;

      */

    /*

      std::cout<<"数据包发送和接收时间"<<std::endl;

      for (uint32_t i = 0; i < sendTime.size (); i++)

       {

          std::cout<<sendTime [i].GetSeconds ()<<"S 发送了一个数据包"<<"序列号是"<<sendSeq [i]<<std::endl;

       }

      for (uint32_t i = 0; i < receiveTime.size (); i++){

              std::cout<<receiveTime [i].GetSeconds ()<<"S 接收了一个数据包"<<"序列号是"<<receiveSeq [i]<<std::endl;

      }

      */

}

void OrrpExample::InstallApplications()

{

    std::string dataRate = "1Mbps"; // size of packet, 5/8*1024*1024/1472

    //  std::string dataRate = "1Mbps";

    PacketSinkHelper sinkHelper("ns3::UdpSocketFactory", InetSocketAddress(Ipv4Address::GetAny(), 9));

    //  sinkHelper.SetAttribute("EnableSeqTsSizeHeader",BooleanValue (true));

    // 目的节点 ->sinkApp

    ApplicationContainer sinkApp = sinkHelper.Install(nodes.Get(size - 1));

    sink = StaticCast<PacketSink>(sinkApp.Get(0));

    Address remoteAddress;

    remoteAddress = InetSocketAddress(interfaces.GetAddress(size - 1), 9);

    /* Install TCP/UDP Transmitter on the station */

    OnOffHelper sourceHelper("ns3::UdpSocketFactory", Address());

    //  OnOffHelper sourceHelper ("ns3::UdpSocketFactory", (InetSocketAddress (interfaces.GetAddress (size-1), 9)));

    sourceHelper.SetAttribute("Remote", AddressValue(remoteAddress));

    sourceHelper.SetAttribute("PacketSize", UintegerValue(256));

    sourceHelper.SetAttribute("OnTime", StringValue("ns3::ConstantRandomVariable[Constant=1]"));

    sourceHelper.SetAttribute("OffTime", StringValue("ns3::ConstantRandomVariable[Constant=0]"));

    sourceHelper.SetAttribute("DataRate", DataRateValue(DataRate(dataRate)));

    sourceHelper.SetAttribute("EnableSeqTsSizeHeader", BooleanValue(true));

    // 发送节点 ->sourceHelperApp

    ApplicationContainer sourceApp = sourceHelper.Install(nodes.Get(0));

    sourceApp.Get(0)->TraceConnectWithoutContext("Tx", MakeCallback(&TxPacket));

    source = StaticCast<OnOffApplication>(sourceApp.Get(0));

    // 接收应用启动时间

    sinkApp.Start(Seconds(3.0));

    // 发送应用启动时间

    sourceApp.Start(Seconds(3.0));

    Config::ConnectWithoutContext("/NodeList/*/ApplicationList/*/$ns3::PacketSink/Rx", MakeCallback(&OrrpExample::ReceivePacket, this));

    // progress

    Simulator::Schedule(Seconds(totalTime / 100), &PrintProgress, totalTime);

    //  Simulator::Schedule (Seconds (6.0), &OrrpExample::CalculateThroughput,this,totalTime-0.5);

    //  Simulator::Schedule(Seconds(totalTime)-Seconds(0.1),&writeData);

    sinkApp.Stop(Seconds(totalTime) - Seconds(0.2));

    sourceApp.Stop(Seconds(totalTime) - Seconds(2));

    //  printRoute(1.02017);

}
